• Dual-halogen composite headlamps
  • Direct light to help improve down-the-road visibility during nighttime driving
• 16" x 6.5" steel wheels
  • Gray center caps
• Flasher
  • Heavy-duty, LED
• Solar-Ray^® light-tinted glass
  • Used on windshield and front doors to help minimize interior heat buildup and direct glare caused by the suns rays
• 16" LT225/75R16E all-season blackwall rear tires
• Dual Rear Wheels
• Front license plate kit
• Front intermittent wipers
  • Variable-speed
  • Washers to keep the windshield clean
• 16" LT225/75R16E all-season blackwall front tires
• Summit White
• Velvac outside wide-stance sail panel mounted mirrors
  • Velvac convex driver and passenger outside mirrors, sail panel mounted with arms that provide a wide stance
  • 63.3 square-inch flat glass positioned over a 30.1 square-inch convex glass mounted in a common head
  • Can be utilized with bodies up to 96-inches in width
  • Shipped loose in vehicle for dealer or upfitter installation
• Tire valve stems, brass in lieu of standard Also included on spare when furnished
• Paint, solid
• Chrome grille
  • Makes a bold statement with this available Chrome grille
  • May require additional optional equipment
• Chrome front bumper
• Hubcap delete

• Driver Information Center
  • Includes warning messages and vehicle information
  • Average vehicle speed and fuel economy
  • Fuel range
  • Trip odometer
  • Tire pressure and oil life
• Heater and defogger
  • Includes windshield and side window defoggers
• 120-volt power outlet
  • 3-prong auxiliary household-style outlet
  • Can be used to plug in electrical equipment, such as a cell phone or a portable device
• Air conditioning
  • Cools and dehumidifies the air inside the vehicle
  • Allows you to manually control temperature, fan speed and sources of airflow
• Interior lighting
  • Dome light
  • Door handle activated switches
• Assist handles
  • Front A-pillar mounted for Driver and Passenger
• Cloth headliner
• Driver and front passenger high-back bucket seats
  • With head restraints and vinyl or cloth trim
• Warning tones
  • Headlamp on and key-in-ignition
• Medium Pewter, Custom Cloth seat trim
• Cloth front bucket seats
  • High back bucket seats
  • Each seat has its own armrest and head restraint
  • May require additional optional equipment
• Key equipment, two additional keys for single key system Provides two additional spare keys for a total of (4). (Keys will be cut but not programmed) NOTE: programming of keys is at customer's expense. Programming keys is not a warranty expense.
• Power windows
• Auxiliary rear heater provisions
  • May require additional optional equipment
• Power door locks
  • Allows you to lock and unlock doors easily whether it's from the driver or passenger seat or from outside using the key fob
  • Lockout protection helps you avoid locking keys in the vehicle
• Cruise control
  • Maintains a selected speed while driving
  • Set and resume speed functions
  • May require additional optional equipment
• Driver and front passenger visors
  • Vinyl
• Inside rearview auto-dimming mirror
  • Automatically dims the inside rearview mirror when it senses bright light from behind
  • Includes rear view camera display
• Console, deluxe with swing-out storage bin
  • Keeps valuables and small items secure

• Power steering
• Rear wheel drive
• Incomplete Vehicle Certification
  • May require additional optional equipment
• Standard body
• Suspension, front independent with coil springs and stabilizer bar
• Aluminized stainless-steel muffler and tailpipe
• 14,200 lbs. GVWR
  • When properly equipped; includes weight of vehicle, passengers, cargo and equipment
• Rear hypoid drive axle with multi-leaf spring suspension
• 4.10 rear axle ratio
  • May require additional optional equipment
• 4-wheel antilock disc brakes
  • Help reduce wheel lockup and maintain steering control during hard braking on most slippery surfaces
  • May require additional optional equipment
• Emission System, 10K-14K GVW
• Ladder-type frame
  • High-strength steel
• Fuel, additional 3-gallons 3 gallons of fuel in addition to normal assembly plant fill
• Governor, electronic speed sensor set to 70 MPH Provides electronic software to limit maximum road speed to 70-MPH. Cruise control limited to 65 MPH.
• Wiring junction block accessory equipment
  • 2-30 amp circuits
  • May require additional optional equipment
• 220-amp alternator
  • May require additional optional equipment
• Emissions, Colorado, Connecticut, Delaware, Maine, Maryland, Massachusetts, Minnesota, Nevada, New Jersey, New Mexico, New York, Oregon, Pennsylvania, Rhode Island, Vermont and Washington state requirements
• Soft-mount body-mount "donuts" and bolts
  • Designed for mounting an upfit body to vehicle chassis
• Heavy-duty 770 cold-cranking amps Isolated second heavy-duty battery
  • Battery, 770 cold-cranking amps primary
  • Isolated second heavy-duty 770 cold-cranking amps
  • Allows second battery to be used when the vehicle is not running without affecting ability to start the vehicle
  • May require additional optional equipment
• Stop/Turn Signal circuits
  • Body Control Module calibration that allows the stop and turn signals to be operated separately
• Trailer wiring with dual 4-pin/7-pin sealed connector
• 57 gallon fuel tank
  • Includes auxiliary feed fuel fitting and in-tank return line
  • May require additional optional equipment
• Emissions override, Federal
• Automatic locking rear differential
  • When the differential senses a significant difference in wheel speed, it locks to turn both rear wheels in unison for added traction
  • The Eaton^® Locker senses a difference in wheel speed of approximately 100 rpm

• Chrome Appearance Package
  • Front and rear chrome bumpers
  • Chrome grille
• Driver Convenience Package
  • Tilt steering wheel
  • Cruise control
• Shuttle Bus Package
  • Available on 3500 139" and 159" wheelbases and all 4500 models
  • Chrome Appearance Package
  • Chrome front bumper
  • Chrome grille
  • Driver Convenience Package
  • Tilt-steering wheel
  • Cruise control
  • 220-amp alternator
  • Dual batteries (770 cca primary and 770 cca isolated)
  • Auxiliary rear heater provisions
  • Stop/Turn Signal circuits
  • Wiring junction block for accessory equipment
  • Soft-mount body-mount "donuts" and bolts
  • May require additional optional equipment
• 4500 Van Preferred Equipment Group Includes standard equipment
• Power Convenience Package
  • Power windows
  • Power door locks

• Label, fasten seat belts "Fasten Seat Belts" reminder label on right-hand and left-hand front side door glass
• Fleet Processing Option

• Daytime Running Lamps

• Airbag deactivation switch, frontal passenger-side (Not available with (AJ3) frontal, driver-side only airbag. Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
• 2 airbags
  • Frontal airbags for driver and front passenger¹
• OnStar Basics
  • Drive confidently with core OnStar services including¹
  • Remote commands
  • Built-in voice assistance
  • Real-time traffic and navigation
  • Automatic Crash Response to help if you're in need
• Back-up alarm, 97 decibels Alarm shipped loose to be installed by upfitter.
• Dual-note horn
• Seat belts, Orange Provides high visibility front Orange seat belts in lieu of Dark Pewter
• Rear Vision Camera
  • When in Reverse, shows you an image of the area directly behind your vehicle¹
  • Can help you park and avoid vehicles and objects
  • You can also display an overlay of where your vehicle is heading

• Hill Start Assist
  • When you are stopped on an incline, this feature keeps the brakes engaged for a split second as you transition from brake pedal to gas pedal
  • Automatically releases once you press down on the accelerator
  • Prevent vehicle roll-back while the driver moves his/her foot from the brake to the accelerator pedal

Shuttle Bus Package

Power Convenience Package

• DriveType
• DriveType: Rear Wheel Drive
• Fuel Economy
• City: 0 MPG
• Hwy: 0 MPG
• Combined: 0 MPG
• Fuel System
• Fuel System: Electronic Fuel Injection
• Fuel Tank Capacity
• Fuel Tank Capacity: 57 gal
• Fuel Type
• Fuel Type: Gasoline Fuel
• Horse Power
• Horse Power: 401
• Rear Wheel
• Rear Wheel: Dual
• Trailering Capacity
• Trailering Capacity: 0
